Raptor 90 LED 20.5″ Light Bar
Made in Australia – Designed and built for some of the toughest environments on earth.
Available with either 4000k or 5700k Colour Temperature
5 Year Warranty and the option to extend by a further year
Suits DV12H Harness – Sold Separately
90W RAPTOR LIGHT BAR SPECIFICATIONS | |
Wattage | 90 Watts |
Light Source | 18 x 5w LED's |
Light Output – Raw | 10,800 Lumens |
Light Output – Effective | 8,650 Lumens |
Voltage | 9-36V |
Current Draw | 6.7A @ 13.5V |
Operating Temp. | -40 to 80 Deg C |
Waterproof Rating | IP67 |
Connector Type Plugs | 2 Pin Heavy Duty Deutsch |
Housing | Aluminium |
Lens Construction | Polycarbonate |
Bracket | Stainless Steel |
Colour Temperature | 4000K or 5700K |
Lifespan | 50,000 Hours |
Dimensions | 523 x 45 x 73mm |
Net Weight | 1.7kg |
Mounting Suitable | Side Mounts |
Beams Type | Combo or Spread |
Warranty | 5 Years |
Harness | Harness not included, purchased separately. Harness to suit: DV12H |
Part Number |
|
Combo, 5700K | RAP090LBv2 |
Spread, 5700K | RAP090LBSv2 |
Combo, 4000K | RAP090LB4v2 |
Spread, 4000K | RAP090LB4Sv2 |
